LW L-50100 100MHZ Analog Oscilloscope Dual Channel Desktop Oscilloscope for Laboratory Teaching

Description

LW L-50100 100MHZ Analog Oscilloscope Dual Channel Desktop Oscilloscope for Laboratory Teaching

Product Information

1, bandwidth: DC 100MHz
2, highly sensitive: sensitivity is 1mV / per division
3, CRT: 6-inch large screen for easy observation of measurement waveforms, there are red scale planning lines in the screen to facilitate the measurement of measured waveforms.
4, DC compensation: (LW5040, LW-5060, LW-50100 have) When the input waveform is a large waveform, it can be monitored
5, ALTMAG: (LW5040, LW-5060, LW-50100 have) synchronous observation of X1 or X10 scan waveform
6. ALT trigger: When two channels simultaneously input waveforms of different frequencies, this function can stably obtain two waveforms.
7, TV signal synchronization with the same energy: with TV synchronous separation line to stably receive TV signals
8. Dual-pass/double-track X-Y operation: When set in the X-Y position, it can be used as an x-y oscilloscope. CH1 is the horizontal axis and CH2 is the vertical axis.
9, trigger mode: automatic, normal, TV, TV line
10, vertical mode: alternating, intermittent, adding
11, input AC voltage 220v (110v optional)

Technology Parameter

Paramete		Mode
		L-212		L-5040	L-5060	L-50100
Frequency domain		DC-20MHz		DC-40MHz	DC-60MHz	DC-100MHz
In case the screen		8*10div(1div=1cm)		8*10div	8*10div	8*10div
Vertical deflection	display mode	CH1 CH2 CH3 ADD ALT CHOP
	deflection factor	5mV/div to 5V/div±3%(1mV/div±5%)
	Rise time	≤17.2ns	≤17.2ns		≤17.2ns	≤17.2ns
	polarity selection	±CH2
	maximum input voltage	250V (≤1KHz)
Horizontal deflection	display mode	1,10,X-Y
	time base	0.2us/div~0.2s/div	0.2us/div~0.2s/div		0.2us/div~0.2s/div		0.2us/div~0.2s/div
	Sweep width	×10	×10		×10		×10
	Precision	3%	3%		3%		3%
Waveform correction		Frequency 1KHz 20% voltage: 0.5v 1%
input impedance		1MΩ	1MΩ		1MΩ		1MΩ
Size		370x310x130mm
Weight		8Kg
