Heating Instrument

Home / Laboratory Equipments / Digital Heating Mantle 2000ml Magnetic Stirring 2L Laboratory Flask Heater 98-III-B

Digital Heating Mantle 2000ml Magnetic Stirring 2L Laboratory Flask Heater 98-III-B

Power supply: 110v/60Hz; Stirring volume: 2000ml; Heating power: 530W; Maximum temperature: 380 ° C;Stirring speed: 60 ~ 2300 rpm / MIN, Motor power: 40W; Temperature control accuracy: ± 0.2 ° C, 0.1 ° C display; Timing error:<1%.
Cold plate stretching shell, strong and durable, high-temperature resistance fiberglass is used as insulation materials, aluminum silicate used for cotton insulation, resistance wire of Cr20Ni80 material is sealed in the insulation layer and weaved into hemispherical internal heater.
Heating and stirring two-way switch control. Intelligent PID temperature control, one-key conversion, first PT100 thermal resistance, second K-type thermocouple.
Comes with (1) 19inch vertical rod, (2) extended thermo probes (16inch), (1) magnetic pill (1 1/8 inch) and (1) rod clamp.

Description

Specifications for this item

Product details

  • Product Dimensions ‏ : ‎ 15 x 10.5 x 8 inches; 24 Pounds
  • Date First Available ‏ : ‎ February 4, 2022
  • Manufacturer ‏ : ‎ Generic
  • ASIN ‏ : ‎ B07HRN3MGF

Product Description

TECHNICAL PARAMETERS:-Power supply: 110v/60Hz.-Stirring volume: 2000ml.-Heating power: 530W.-Maximum temperature: 380 ° C.-Stirring speed: 60 ~ 2300rpm / MIN, digital display, button adjustment.-Motor power: 40W.-Temperature control accuracy: ± 0.2 ° C, 0.1 ° C display.-Time setting range: 0-9999 minutes, digital display, timing error<1%.-Liquid crystal display: speed, temperature, timing.-Comes with vertical threaded lab stand and clamp for short path head securing.-Self-contained sensor off detection function.-Built-in temperature limit detection function prevents over temperature.-DC permanent magnet motor, low noise, large torque and long life.-Low speed and stable, high speed and strong.-The bevel control panel is suitable for sitting and standing viewing angles.-The appearance is streamlined design, no dirt, easy to wipe.-Water boiling: 8~15 minutes.-Inner bowl diameter: 6.5inches. (max diameter of boiling flask)-Furnace wire: Cr20Ni80.-Insulation Layer: alkali-free glass fiber, can withstand 450 degrees.-Insulation coefficient: ≥500 megawatts when relative humidity ≤35%.-Warm layer: aluminum silicate cotton insulation.-Working hours: continuous.-Instructions for use of Heating Mantle are in the box.PRECAUTIONS:1▲When using the mantle for the first time, there will be white smoke and odor coming from the sleeve. It is normal for the color to change from white to brown and then white. Because the glass fiber contains oily and other compounds from the production process, it should be placed in well ventilated area or outside. After a few minutes smoking will disappear, then mantle can be used normally.2▲The instrument should have good grounding.
